RS PRO IDM17 Probe Style Digital Multimeter
RS PRO IDM17 probe style multimeter offers a clear 3200 Count LCD display, 65 segment bar graph and annunciators. These devices can measure resistance, voltage, and electrical current with diode and continuity check. This small handheld meter is truly portable, rugged in construction, lightweight and very easy to use.
This multimeter is ideal for a wide range of sectors i.e. Mechanical Industries, Test and Measurement and Automotive applications.
RS PRO range of handheld and bench digital multimeters are RS approved meaning that they are great value for money and high quality you can rely on.
Features and Benefits
Autoranging and manual selection
Mains proof Ω/continuity ranges
600 V protection in every range
Fast continuity beeper
Data hold function
Auto power off
Standard "AAA" size batteries (supplied fitted)
Long battery life
Standard " pitch input jacks
Rugged construction with high impact thermoplastic case
Designed to meet IEC 1010-1 (safety standard)
Installation category III 300 V
Installation category II 600 V
What do you get?
Test lead (one black)
Test probe (Red)
Why would you buy this product?
In addition to an exceptional technical specification, this unique pen style multimeter offers a level of safety normally only found on larger hand held multimeters.
This instrument has been designed in accordance with UL 3111-1 and IEC publication 1010 Pt1, Class II, Safety Requirements for Electrical Equipment for measurement, control and laboratory use. This level of safety can only be guaranteed while the appropriate limits are observed.
A digital multimeter is a handy test tool that measures electrical values such as voltage, current, and resistance. A DMM is used by technicians in the following areas:
Electrical and electronic industriesSafety guidelines
When using any electrical test equipment it is advised that you refer to the users manual for proper working operating procedures and safety precautions in order to avoid potential safety hazards.
|Multimeter Type||Handheld |
|Absolute Maximum AC Current Measurement||100A ac |
|Absolute Maximum Resistance Measurement||30MΩ |
|Absolute Maximum DC Voltage Measurement||600V dc |
|Absolute Maximum AC Voltage Measurement||600V ac |
|Functions Measured||AC Current |
|True RMS||No |
|Display Type||Digital |
|Model Number p||IDM17 |
|AC Current Measurement Resolution||0.001mA ac |
|AC Voltage Measurement Resolution||1mV ac |
|Maximum Operating Temperature||+50°C |
|Safety Category Voltage||300V |
|Best DC Voltage Accuracy||±0.7 % |
|Dimensions||78 x 42 x 203mm |
|Battery Type||AAA 1.5 V (IEC LR03) |
|Minimum Operating Temperature||0°C |
|Best AC Current Accuracy||±1% + 3 Digits |
|Safety Category Level||CAT III |
|Battery Life||800 h |
